Product Abstract:

UQK-652-C type level alarm controller is designed for heavy duty working in high viscosity liquid, it is widely used for all kinds of ships to monitor the bilge well level alarm.


Product Description



UQK-652-C Marine Float Level Controller



Technical Specification

  • Model:

    UQK-652-C , UQK-652-C-B , UQK-652-C-Z
  • Material:

    Aluminium , Stainless Steel
  • Control Range:

    300 ~ 2500 mm
  • Mounting Type:

    Horizontal Mounting , Vertical Mounting
  • Protect Pipe:

    Φ76mm , Φ89mm
  • Float Ball:

    Φ60mm , Φ76mm
  • Contact Capacity:

    250V , 10A
  • Protection:

    IP66 , IP68
  • Explosion Proof:

    Exd IICT6
  • Medium Tem.:

    ≤ 150℃
  • HS Code:

    9026209000
  • Dimension:

    L x 190 x 190 mm
  • Weight:

    20Kg
  • Application:

    Oil Tank , Water Tank , etc...
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
