Product Abstract:

ULB-3G Marine Boiler Level Gauge is used to measure the level of marine boiler and other industrial boiler.


Product Description



ULB-3G China Marine Boiler Level Gauge



Basic Information

  • Glass Material:

    Toughened Borosilicate Glass
  • Body Material:

    20Mn Forging Steel
  • Working Pressure:

    ULB-3GR Reflex Type 2.5 Mpa / ULB-3GT Transparent Type 4.0 Mpa
  • Working Temp.:

    ULB-3GR Reflex Type 220 ℃ / ULB-3GT Transparent Type 260 ℃
  • Connection Flange:

    Standard: DIN or JIS or ANSI , Size: 20A or 25A
  • Medium:

    Steam or Water
  • Measuring Range:

    310 ~ 2235 mm
  • Application:

    Marine Boiler , Industrial Boiler
  • HS Code:

    90261000
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
