Reverse Domed Scored Bursting Disc

Product Abstract:

Shanghai Huali YC type and Chengdu Chenghang YC type reverse domed scored bursting disc is non reclosing safety devices with precisely defined breaking pressure.

Product Description



China Reverse Domed Scored Bursting Disc



Technical Specification

  • Origin:

    Made In China
  • Export Market:

    USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc...
  • Related Model:

    YC, YCJ, YCP, YCH
  • Structure:

    Reverse Domed Scored YC Type Bursting Disc
  • Feature:

    No fragments and sparks are generated in bursting.
  • Application:

    Applied to vacuum or gas environment with a medium or fluctuating pressure.
  • Nominal Diameter:

    20mm,25mm,32mm,40mm,50mm,65mm,80mm...450mm,500mm,550mm,600mm
  • Bursting Pressure:

    0.1Mpa ~ 11Mpa
  • Temperature:

    Maximum Service Temperature -196℃ ~ 530℃
  • Disc Material:

    Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium
  • Disk Form:

    Reverse domed bursting disc,Reverse domed welded bursting disc
  • Holder Type:

    Y0JA, LJC
  • HS Code:

    8479909090
  • Dimension:

    20mm ~ 600mm
  • Weight:

    0.5Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS
  • For More Information:

    Please feel free to contact with Lead Marine.
