RDLY-1d Pressure Transmitter

Product Abstract:

Shanghai Rongde Engineering RDLY-1d pressure transmitter is widely used to monitor the pressure of tanks for all kinds of ships.

Product Description



RDLY-1D Rongde Pressure Transmitter



Technical Specification

  • Original:

    Made In China
  • Market:

    China, USA, Europe, Japan, Korea, Singapore, Indonesia, U.A.E., India, etc...
  • Model:

    RDLY-1, RDLY-1a, RDLY-1d, RDLY-2a, RDLY-2b, RDLY-2c, RDLY-S
  • Power:

    DC24V
  • Output Signal:

    4~20mA Current Signal
  • Measuring Range:

    -10~30Kpa , 0~0.6Mpa , 0~1Mpa , 0~1.6Mpa , 0~6Mpa , etc...
  • Connection:

    M20X1.5
  • Protection:

    IP66
  • Explosion Proof:

    ExiaIICT6
  • HS Code:

    9026209000
  • Dimension:

    40x50x140 mm
  • Weight:

    2 Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
