MIND Electrical Time Delay Relay

  • MIND Electrical Time Delay Relay
  • MIND HH52P Relay

Product Abstract:

WUXI MIND ELECTRIC JSZ8 Series electrical time delay relay can be used for timing control units, which make and break circuits according to setting time. Mind time relay acquires with the attestation of CCC.


Product Description



MIND JSZ8 Time Relay



Technical Specifications

  • Standard:

    In compliance with the standard of GB14048 and DIN.
  • On Delay:

    JSZ8-01A, JSZ8-02A, JSZ8-03A, JSZ8-04A, JSZ8-05A
  • Interval Timing:

    JSZ8-01G, JSZ8-02G, JSZ8-03G, JSZ8-04G, JSZ8-05G
  • With Inst. Contact:

    JSZ8-01C, JSZ8-02C, JSZ8-03C, JSZ8-04C, JSZ8-05C
  • Off Delay:

    JSZ8-11F, JSZ8-13F, JSZ8-14F, JSZ8-15F, JSZ8-16F
  • Star-Delta Timing:

    JSZ8-Y
  • Two Wire On Delay:

    JSZ8-01X, JSZ8-02X, JSZ8-03X, JSZ8-04X, JSZ8-05X
  • Voltage:

    AC24V, AC110V, AC220V, DC24V, DC48V
  • Timing Range:

    0.1~1 ,0.5~5 , 1~10 , 3~30 , 6~60 s/min
  • Reset Time:

    60ms
  • Insulation Resistance:

    100MΩ
  • Advantages:

    Small Size, High Timing Accuracy, High Reliability, Long Life, Etc...
  • HS Code:

    8537209000
  • Dimension:

    105 x 75 x 22.5 mm
  • Weight:

    110g
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
