Marine Explosion-proof Motor

Product Abstract:

DEZHOU HENGLI YB2 Series marine explosion-proof motors are used within a wide variety of applications in hazardous areas.

Product Description

Marine Explosion-proof Motor

Basic Information

Type:
YB2-63M1-2, YB2-90S-2, YB2-180M-4, YB2-180L-6, YB2-200L-8, YB2-315M-10, etc...
Standard No.:
IEC60079-0, IEC60079-1, IEC60079-70, IEC60079-31
HS Code:
8501520000
Insulation:
Class B , Class F
Protection:
IP44
Explosion-proof:
Exd-IIA , Exd-IIB , Exd-IIC
Frame:
63M, 71M, 80M, 90S, 90L, 100L, 112M, 132S, 132M, 160M, etc...
No. of Poles:
2 , 4 , 6 , 8 , 10
Power:
0.55 kw - 315 kw
Voltage:
380V , 400V , 415V , 440V , etc...
Frequency:
50HZ / 60HZ
Lead Time:
Around 10 Days
Certificate:
ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.

Class Certificate
