Product Abstract:

CWF series marine pulverizing pump is application for the sewage treatment system, at the inlet of the pump use the knift-edges impeller to pulverize the fouls in the sewage.


Product Description



Marine Crushing Pump



Technical Specification

  • Model:

    0.5CWF-6(B), 0.5CWF-10(B), 0.5CWF-15(B), 0.5CWF-20(B), 0.5CWF-30(B), 1CWF-11(B)
  • Model:

    1CWF-20(B), 1CWF-30(B), 2CWF-11(B), 2CWF-20(B), 2CWF-30(B), 3CWF-10(B)
  • Flowrate:

    5m³/h , 10m³/h , 20m³/h , 30m³/h
  • Pressure:

    0.06Mpa , 0.10Mpa , 0.11Mpa , 0.15Mpa , 0.20Mpa , 0.30Mpa
  • Voltage:

    220V , 380V , 400V , 415V , 440V
  • Frequency:

    50HZ , 60HZ
  • Motor Power:

    0.75KW , 1.1KW , 1.5KW , 2.2KW , 3.0KW , 4.0KW , 5.5KW
  • Inlet Diameter:

    50mm , 65mm
  • Outlet Diameter:

    32mm , 40mm , 50mm
  • HS Code:

    68061000
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
