Sliding Type Expansion Joint
Product Name:
Sliding Type Expansion JointModel No.:
STL
Product Abstract:
Marine slip-on joint is suitable for ship air, water and oil transfer piping lines, the flange standard, materials and coating can be decided according to your requirement.- Product Description
China Sliding Type Expansion Joint
Technical Specifications
-
Slip Type:
Dresser Type , Sleeve Type -
Approval Standard:
CBM1129-82 , GB/T12465-2002 , IACS P2.11 -
Displace:
90mm -
Design Pressure:
1.6Mpa , 1.0Mpa -
Design Temperature:
NBR: 80℃ , FKM and Viton：150℃ , Silicon: 180℃ -
Material:
Carbon Steel , SUS304 -
Seal Ring:
NBR , FKM , SILICON , VITON -
Nominal Diameter:
DN65,DN80,DN100,DN125,DN150,DN200,DN250,DN300,DN350,DN400, Etc... -
Pipe Outer Diameter:
76,89,114,140,168,219,273,325,377,426,480,508,630 mm -
Application:
Piping Lines : Oil , Sea Water , Fresh Water , Air -
IMPA Code:
84031090 -
HS Code:
735001,735002,735003,735004,735005,735006,735007,735008,735009,735010,etc... -
Dimension:
155x155x230mm -
Weight:
5Kg -
Lead Time:
5 Days. -
Certificate:
ABS , BV , BKI , CCS , DNV , GL , LR , KR , NK , RINA , RS -
For More Information:
Please feel free to contact with Lead Marine.
-
