Reverse Slotted Domed Bursting Disc
Product Name:
Reverse Slotted Domed Bursting DiscModel No.:
YK , YF
Product Abstract:
Shanghai Huali Safety Devices reverse slotted domed YK bursting disc and YF bursting disc is composed of sawteeth pressure sensitive components, pressure levers and a sealing film.- Product Description
China Reverse Slotted Domed Bursting Disc
Technical Specification
-
Origin:
Made In China -
Export Market:
USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc... -
Related Model:
YK, YF -
Structure:
Reverse Slotted Domed YK Type Bursting Disc -
Feature:
No sparks are generated in bursting. -
Application:
Applied to gas and gas-liquid medium in the places with low pressure. -
Nominal Diameter:
20mm,25mm,32mm,40mm,50mm,65mm,80mm...300mm,350mm,400mm,450mm -
Bursting Pressure:
0.005Mpa ~ 7Mpa -
Temperature:
Maximum Service Temperature -196℃ ~ 530℃ -
Disc Material:
Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium -
Disk Form:
Reverse Slotted Domed YF Type Bursting Disc -
Holder Type:
Y0JA -
HS Code:
8479909090 -
Dimension:
20mm ~ 450mm -
Weight:
0.5Kg -
Lead Time:
Stock Available. -
Certificate:
ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS -
For More Information:
Please feel free to contact with Lead Marine.
-
