Oil Water Interface Detector

Product Abstract:

The portable oil/water interface detector is designed for measuring the oil-water interface level for cargo tanker, widely used for oil tankers and chemical tankers.

Product Description



China Portable Ullage Oil Water Interface Detector



Technical Specification

  • Related Model:

    UBX, UTL-200, T2000-TFC-02, T2000-TFS-01, TSS-01, TSS-02, UTI Meter Rtex, UTI Meter Gtex
  • Regulations:

    IMO MARPOL 73-78 ANNEX I , IMO RESOLUTION MEPC.5(XIII).
  • Function:

    Portable measuring system check the tank status for effective management of the storage tank.
  • Tape Length:

    15M , 30M , 40M
  • Diameter of Probe:

    34mm
  • Accuracy:

    ±2mm , ±20mm
  • Responding Time:

    <3s
  • Protection:

    IP44
  • Explosion-proof:

    ExiaIIBT4
  • HS Code:

    9026209000
  • Application:

    All kinds of oil and chemical tankers.
  • Dimension:

    600x350x150mm
  • Weight:

    7Kg
  • Lead Time:

    10 Days
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
