China Bursting Disk

Product Abstract:

Chengdu Chenghang LC type and Shanghai Huali LC type domed scored bursting disc is designed with a cross or annular score made in the dome to weaken the strength.

Product Description



China Bursting Disks



Technical Specification

  • Origin:

    Made In China
  • Export Market:

    USA, Europe, Japan, Korea, Singapore, Indonesia, India, etc...
  • Structure:

    Conventional Scored Domed LC Type Bursting Disc
  • Feature:

    No fragments and sparks are generated in bursting.
  • Application:

    Applied to gas or liquid with a medium or high pressure.
  • Nominal Diameter:

    3mm,10mm,20mm,25mm...450mm,500mm,550mm,600mm
  • Bursting Pressure:

    0.2Mpa ~ 80Mpa
  • Temperature:

    Maximum Service Temperature -196℃ ~ 530℃
  • Disc Material:

    Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium
  • Disk Form:

    Domed bursting disc with a cross shaped slot or with a C shaped slot.
  • Holder Type:

    LJC
  • HS Code:

    8479909090
  • Dimension:

    3mm ~ 600mm
  • Weight:

    0.5Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS
  • For More Information:

    Please feel free to contact with Lead Marine.
