China Bursting Disc

Product Abstract:

Shanghai Huali Safety Devices LP series bursting disc is a single layer film, this kind of bursting disk is also called tensile bursting disc.

Product Description

China Bursting Discs

Technical Specification

Related Model:
LP, LPT, LPZ, LPH, LPHZ, LPJ
Structure:
Conventional Simple Domed LP Type Bursting Disc
Application:
Applied to gas or liquid medium with a high temperature or high pressure.
Nominal Diameter:
3,10,20,25,32,40,50,65,80,100,125,150,200,250,300,350,400,450,500,600 mm
Bursting Pressure:
0.15Mpa ~ 100Mpa
Temperature:
Maximum Service Temperature -196℃ ~ 530℃
Disc Material:
Aluminium, Cu, Austenitic Stainless Steel, Nickel, Graphite, Tantalum, Titanium
Sealing Type:
Flat Sealing, Cone Sealing, Flat Sealing With a V Slot
Holder Type:
LJ, LJB
HS Code:
8479909090
Dimension:
3mm ~ 600mm
Weight:
0.5Kg
Lead Time:
Stock Available.
Certificate:
ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS
For More Information:
Please feel free to contact with Lead Marine.
