China Battery Switch

Product Abstract:

China battery switches for marine industry, widely used on ships, yachts and lifeboats, suitable for 6V, 12V, 24V and 32V DC power supply system.

Product Description



China Battery Selector Switches



Technical Specifications

  • Select OFF:

    Complete disconnect of both batteries or banks of batteries.
  • Select 1:

    Operation of NO.1 battery only.
  • Select 2:

    Operation of NO.2 battery only.
  • Select BOTH:

    Operation of both batteries and banks of batteries.
  • Rated Voltage:

    32V
  • Current:

    Continuous :300ADC , Intermittent : 400ADC
  • 4 Position Selector:

    1 - BOTH - 2 - OFF
  • HS Code:

    84253990
  • Dimension:

    48 x 48 x 98 mm
  • Weight:

    0.5Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
