Product Abstract:

Shangdong ChangRun Tech, Shandong Haorun Automation Technology CHR and HR series pressure transmitter is widely used for all kinds of ships.


Product Description



Pressure Transmitter



Technical Specification

  • ChangRun Model:

    CHR2000, CHR2300, CHR2600, CHR2800, CHR3000, CHR3100, CHR3133, CHR3500
  • Shangdong Changrun:

    CHR3016, CHR3026, CYD-1000, CYD-1100, WYS-III, WYZ-1,CHR4300, etc...
  • Shangdong HaoRun:

    HR1002, HR1003-A1, HR1105, HR1103, HR1104, HR1101, HR1102, HR1005-A
  • Shangdong HaoRun:

    HR1006-AH HART, HR1004, HR1007-C, HR1001, HR1201-WP, HR1201-WS, HR4001
  • Shangdong HaoRun:

    HR1202-WP, HR1202-WS, HR1203-WP, HR1203-WS, HR1204-WP, HR1204-WS, HR4002
  • Application:

    Measure pressure of liquids and gas.
  • Measuring Range:

    0 ~ 150Mpa
  • Measuring Accuracy:

    ±0.5%FS
  • Output Signal:

    I4: 4~20mA; U1: 1~5V; U2: 0~5V; U4: 0~100mV; U5: 0.5~4.5V
  • Power:

    24VDC
  • Connection:

    M20x1.5, G1/2, G1/4
  • Protection:

    IP68
  • Explosion Proof:

    ExiaIICT6
  • HS Code:

    9026209000
  • Dimension:

    27x27x135 mm
  • Weight:

    3 Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
