Product Abstract:

YPK-03-C series diaphragm type pressure controller can be used to keep the pressure of water, oil, gas and steam at the setting point.


Product Description



YPK-03-C Marine Pressure Controller



Technical Specification

  • Control Range:

    YPK-03-C-01 : 0.1~0.5 Mpa, YPK-03-C-02 : 0.1~1.2 Mpa, YPK-3-C-03 : 0.6~3 Mpa
  • Accuracy:

    ±0.02 Mpa
  • Contact Capacity:

    AC380V 15A , Two Contacts
  • Protection:

    IP44
  • HS Code:

    9026209000
  • Dimension:

    136 x 136 x 164 mm
  • Weight:

    2.5Kg
  • Application:

    Pressure Water Tank , Hot Water Tank
  • Lead Time:

    Stock Avaiable
  • Certificate:

    ABS , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
