SFAIF Isolation Monitor

Product Abstract:

CMR SFAIF Shanghai ZiYi Marine Instrument Q96 and Q72 isolation monitor for AC and DC power grid is widely used on the ships.

Product Description

SFAIF Marine Isolation Monitor

Technical Specification

Origin:
Made In China
Market:
China, Germany, USA, Europe, Japan, Korea, Singapore, Indonesia, U.A.E., India, etc...
Type:
Q72-MΩA, Q96-MΩA, Q72-ZMΩA, Q96-ZMΩA, Q72-MΩB, Q96-MΩB, Q72-ZMΩB, Q96-ZMΩB
Type:
Q96D-MΩA
Measurement Range:
0~5MΩ
Scale Range:
90°, 240°
Precision:
1.5
Voltage:
24VDC, 100VAC, 220VAC, 380VAC, 400VAC, 415VAC, 440VAC, 450VAC
Alarm Point:
10KΩ, 30KΩ, 60KΩ, 100KΩ, 200KΩ, 300KΩ, 500KΩ, 1MΩ
Option:
Marine Type With Self Test
Protection:
IP42 , IP52
Working Temperature:
-25℃ ~ +55℃
HS Code:
8516609000
Dimension:
72x72x80mm , 72x72x101mm , 96x96x140mm , 96x96x116mm
Weight:
1.5Kg
Lead Time:
Stock Available.
Certificate:
ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
For More Information:
Please feel free to contact with Lead Marine.
