SFAIF Q96-M Insulation Monitor

Product Abstract:

SFAIF CMR SHANGHAI ZI YI MARINE INSTRUMENTATION Q96-MΩA insulation monitor widely used on ships monitoring the AC and DC power grid.

Product Description



SFAIF CMR Q96-M Insulation Monitor



Technical Specification

  • Origin:

    Made In China
  • Market:

    China, Germany, USA, Europe, Japan, Korea, Singapore, Indonesia, U.A.E., India, etc...
  • Related Model:

    Q72-MΩA, Q96-MΩA, Q72-ZMΩA, Q96-ZMΩA, Q72-MΩB, Q96-MΩB, Q72-ZMΩB, Q96-ZMΩB
  • Measurement Range:

    0~5MΩ
  • Scale Range:

    90°, 240°
  • Precision:

    1.5
  • Voltage:

    24VDC, 100VAC, 220VAC, 380VAC, 400VAC, 415VAC, 440VAC, 450VAC
  • Alarm Point:

    10KΩ, 30KΩ, 60KΩ, 100KΩ, 200KΩ, 300KΩ, 500KΩ, 1MΩ
  • Option:

    Marine Type With Self Check Function
  • Protection:

    IP42 , IP52
  • Working Temperature:

    -25℃ ~ +55℃
  • HS Code:

    8516609000
  • Dimension:

    72x72x80mm , 72x72x101mm , 96x96x140mm , 96x96x116mm
  • Weight:

    1.5Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
