QCC14-100A/11 DC Contactor

Product Abstract:

JIANGSU LUTONG ELECTRIC QCC14-100A/11 and QCC14-150A/11 DC contactors are designed to control the line isolation, starting, stopping, reversing, and regulating functions of a DC motor.

Product Description



China DC Contactors



Technical Specification

  • Model:

    QCC14-100A/11 , QCC14-150A/11
  • Main Contact:

    One permanently open , One permanently closed
  • Coil Voltage:

    DC 12V, 24V, 36V, 48V, 60V
  • Load Current:

    100A , 150A
  • Coil Current:

    Max 5A
  • Action Time:

    40ms
  • Dimension:

    86x52x99 mm
  • Weight:

    0.77Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI, BV , CCS , DNV , GL , LR , KR , NK , RINA , RS , IRS
  • For More Information:

    Please feel free to contact with Lead Marine.
