  • Product Name:

    Ship Alarm Horn
  • Model No.:

    BD1-24R
  • Price:

    USD / PC
  • Minimum Order:

    1

Product Abstract:

JIANGYIN UNIVERSAL ELECTRICAL APPARATUS PLANT and JIANGYIN KEJIE ELECTRICAL BD series alarm horn is widely used on the ships, it is meet the requirement of solas.


Product Description



MOELLER ELECTRIC BD1 Alarm Horn



Technical Specification

  • BD1-220G:

    Green, Liferaft Mark, with Flash Lamp
  • BD2-220Q:

    Flush Type
  • BD1-24R:

    Red, CO2 Mark, with Flash Lamp
  • Voltage:

    AC220V , AC110V , AC24V , DC24V
  • Sound Level:

    BD1-220G: 110dB , BD1-220Q: 75dB , BD1-24R: 110dB
  • Working Current:

    BD1-220G ≤ 0.1A , BD2-220Q ≤ 0.1A , BD1-24R ≤ 0.6A
  • Protection:

    IP56 , IP22
  • Sound Type:

    7 SHORT 1 LONG, CONTINUUM, 1 SHORT 1 LONG, CHANGE1, CHANGE2, CHANGE3
  • HS Code:

    84253990
  • Dimension:

    162 X 134 X 198 mm
  • Weight:

    2.0Kg
  • Lead Time:

    Stock Available.
  • Certificate:

    ABS , BKI , BV , CCS , DNV , GL , LR , KR , NK , RINA , RS
  • For More Information:

    Please feel free to contact with Lead Marine.
